CNC WORKING CENTER ZDT-3216

CNC WORKING CENTER ZDT-3216
  • Structure Characteristics

  • Technical Data

  • Detail Description

  • Processing Photos

  • Work Video

  • How To Order

  • FEATURE AND FUNCTION

    The multi-function stone processing machine adopts the latest technologyin domestic and foreign, com bined with the processing in current market.

    It can process in artificial stone. Stone and ceramic plates in one production line for drilling, milling, profiling, grinding, polishing, According to the different models.

    It adopts portal struction wish more strength and stable.

    The main motor adopts high-speed spindle.

    The movement speed uses inverter control The machine is combined with vacuum clamping.

    It can change tools automatically according to the processing steps.

    It is simply to operate with fast processing speed and high precision.







  • MAJOR TECHNICAL PARAMETERS

    Item ZDT-3216 ZDT-2010
    Processing length 3200mm 2000mm
    Processing width 1600mm 1000mm
    Processing thickness <50mm <50mm
    Mikking cutter diameter Φ10-Φ25mm Φ10-Φ25mm
    Drilling wheel diameter Φ10-Φ50mm Φ10-Φ50mm
    Dia of shaping head Φ60-Φ80mm Φ60-Φ80mm
    Dia of polishing head Φ50-Φ100mm Φ50-Φ100mm
    Total power 9kw 9kw
    Outline dimension 5400×3300×2600mm 3600×2200×2200mm
    Weight 3T 2T
    Water consumption 5m³/h 5m³/h
    Air consumption 20L/min 20L/min



    • 1.Contact us

      Contact us by phone/ whatsApp / skype / viber / wechat / email, we will offer you the most suitable quotation

    • 2.Visit

      Check our machines and equipment in our workshops, discuss details and specifications for the production line and customer’s project.We’re also able to arrange the visiting to domestic customer factory to check running line

    • 3.Drawings

      Engineers will design the particular production lines according to customer’s requirements and factory layout; make sure the line fits the workshop perfectly.

    • 4.Finalize contract

      Finalize details for price, payment, shipping time, and sign the contract.

    • 5.Producing

      Start the production immediately the first payment arrives, the sales follow up the production progress and keep customer updated.

    • 6.Inspection

      Assemble the line in our workshop for customer inspection, then pack the whole line according to customer’s requirements.

    • 7.Shipment

      Load the well-packed machines into containers; arrange the shipment by long-cooperated shipping agent, ship to the final port as customer directed. Sales from HG will track the whole procedure, solve problem if there is any.

    • 8.Install

      Send engineers and technicians to customer’s factory, install the whole line, commission the running, make the sure the line is correctly assembled.

    • 9.Train

      Engineers provide the recipe, according to local material condition and their experience. Technicians will also train the workers up until they learn well to operate the machines.

    • 10.After-sale service

      Anytime,any problem,our sales and engineers will try our best to help to solve it.You can contact us by phone/ whatsApp / skype / viber / wechat / email.Our engineers will also go to the customers factory anytime if necessary.
