AUTOMATIC EDGE GRINING MACHINE ZDM-8

AUTOMATIC EDGE GRINING MACHINE ZDM-8

AUTOMATIC EDGE GRINING MACHINE ZDM-8
  • Technical Parameter

  • Structure

  • Processing photos

  • Processing video

  • MAJOR TECHNICAL PARAMETERS

    Item ZDM-8
    Straight line edge grinding length (Continous)
    Number of grinding head 8(Pieces)
    Main engine power 7.5lw×3,5.5kw×5
    Total power 58kw
    Water consumption 6m³/h
    Processing width 1200mm
    Outline dimension 5200×2200×1600mm
    Weight 5T
  • FEATURE AND FUNCTION

    This machine adopts eight-heads structure with quick molding and polishing to finish all the process in one time.

    The speed of the conveyor is controlled by the inverter.

    The abrasive tools are consumption by cylinder.

    This machine is particularly suitable for large projects which have mass production to process.

    This machine is working with good stable and high eficiency, this is our latest model in grinding machine.







Zhejiang Haigong Machinery Co., Ltd. is well-known China AUTOMATIC EDGE GRINING MACHINE ZDM-8 suppliers and AUTOMATIC EDGE GRINING MACHINE ZDM-8 company, set up in 1978 and it is located in TAIZHOU, a coast city in the Yangtze delta with an advanced economy and convenient transportation. Now with an area of 80,000 square meters, intelligent office building and 50,000 square meters modern standard factories contain welding, casting and another three production areas. It has become a high technology enterprise at the command of research, manufacture, selling and after-sales service to produce stone machinery professionally. We were awarded as one of the Top ten of CISE Chinese stone machinery, and also one of the ten top brands among Chinese stone machinery, and also passed CE certification and so on.
We established our production line to introduce the world-class production equipment for planer, grinding rails, large floor lathes, horizontal boring machine, CNC lathe, and other major processing equipment are from famous international equipment suppliers. Our major products are infrared bridge cutting machine, PLC automatic profile cutter, bridge edge grinding machine, bridge edge cutting machine, edge cutting and grinding machine and also arc edge polishing machine, line polishing machine, wholesale AUTOMATIC EDGE GRINING MACHINE ZDM-8 and so on which made by our under-company: ZHEJIANG HAIGONG MACHINERY CO.,LTD” with all the brand of ZHENGDA”.
